This is my damaged Nokia 808. Bella dropped it from 1m height, on a wooden floor. Glass broke, but sceen and touch were intact. I glued screen protection sticker on it, to re-inforce screen a bit and prevent cuts while using it for couple of weeks, while figuring out my repair options.
Authorized repair quoted me 200 EUR for the job of replacing both glass and display together and said, that, according to Nokia manual, it is impossible (or prohibited) to dismantle lcd/glass assembly. There is however a separate glass part available from ebay seller “easyworldwidetrading” (also ewwt-au, ewwtnet, ewwt-oz), for mere 20 EUR (price delivered to Europe). I ordered slightly more expensive kit (25 EUR), which included 2 plastic separation tools, and 2 smallish screwdrivers (one of the Torx T5). In my case, those tools weren’t much help. Moreover, one needs Torx T6 instead, to disassemble Nokia 808. I had to buy it separately at the last moment at the local DIY hypermarket. So, if I had to do it again, I would buy a cheaper kit, without tools. NB! Screen is identical to Nokia’s orginial part, but there is small mark on the upper front lip saying “proto.nokia.com”. This will give away that you tempered with device, and will most probably void warranty.
There are 2 videos available on youtube, from LE55ONS. First, explains how to take out LCD+glass assembly out.
2nd video explains how to separate LCD from glass/digitizer.
After this, you still need to separate glass from the carrying plastic frame, and there is no video on youtube to guide you. This operation is quite messy and time consuming, but you can do it too, just don’t rush and give yourself plenty of time. I never repaired phones before, and doing this first time took about 2 hours for disassebmly and 1 hour to glue parts and put everything back together.
LAST REMINDER, this is messy, fragile, risky. You may damage underlying AMOLED display and of course, even if successful, it voids manufacturer’s warranty.
This is how I thought I would proceed.
But despite continuosly heating the screen and frame, I could not separate it from the frame. The problem was when trying to separate glass from frame, separation tools would go in-between glass and digitizer (both glued to each other as well).
After half and hour of trying around edges, I went for more aggressive approach and ran separator between glass and digitizer. (continue heating).
Notice, how this credit card goes between 2 glass surfaces. By the way, sharpened edge of the old credit card, is all the tool you will need. Well, maybe 2 cards. Be careful with the frame. Breaking glass is ok at this point, breaking the frame is not.
This is what I had after separating the upper glass from the frame. Digitizer screen is very fragile, broken easily. However, new replacement part comes with the new digitizer.
Now, I cleaned the frame from the remaining glass and glue.
Result. Frame (backside) separated from front glass, digitizer in pieces.
I used simple rubbery adhesive glue, the one that needs to dry for couple of minutes before pressing both surfaces. You could use a superfast and super strong glue too, but if you ever need to repeat this procedure, only rubber glue would allow it. I had to work quickly and carefully, with a narrow screwdriver, to apply very thin layer of glue around the digitizer’s position on the frame, to avoid any glue going between glass and AMOLED display, when parts are pressed strongly to each other. Did not have time to make photos, as glue was drying rapidly. Keep protective pads on both sides of the glass.
Then, I connected all electrical parts and powered the phone up. It worked. (including touch)
Went back to AMOLED and glass. Used dry cloth on amoled, then used vacuum cleaner to suck all dust from amoled, (repeat couple of times) then removed protective film from digitizer and clicked amoled and glass together. Powered all electronics on again, checked that there is no dust between glass and display, no traces of glue, etc. Finally, assembled the phone.
Before and After. Good luck if you try this yourself.
This is something I was surprised to find. Switch app does not appear in the menu, but if you press search button (on the homescreen menu) and search for “switch”, one of the results will be “Phone Switch App”.
Or just find it under Phone-> Settings->Connectivity->Data transfer->Phone Switch
I have been using http://wuala.com for couple of years to keep ca 80GB in safely synced and backed up in the cloud, for free. But they changed from p2p storage to commercial centralized server model, as a result, I am going to loose that free storage. What are my options at the moment?
I took a look at
- Windows Live Mesh (will become Windows SkyDrive and loose p2p sync ability). Storage limit is good though at 25GB.
- I have beta invite from Cubby (by LogMeIn) – only 5GB in the cloud, but promise of free and unlimited p2p sync
- Google Drive – only 5GB, but good gmail/gdocs integration, no p2p sync
- Dropbox – up to 16GB storage after referrals, hmm. Plenty of mobile clients, but nothing else going for it, other than ability to game it easily to grow storage.
- Ubuntu One, SugarSync, Megacloud – 5GB free cloud, some mobile clients
- Bitcasa – speaks about unlimited cloud storage for $10/month, using p2p similar to wuala?
I am sorry, to see wuala go nuts like this. Theirs was the best option for owners of 24x7 servers (e.g. home NAS + torrent server + wuala cloud peer). After fallout, not many options are left, most of them are good for usual users, who do not have own server and fully depend on the cloud for sync. However, I see opportunity to achieve most of what wuala did for free by combining various parts of different services.
Here is what I’m going to try
1) for unlimited p2p sync (which provides backup too) between my server and several laptops
2) to raise protection bar – e.g. unlikely event that both laptops and server are destroyed by fire at the same time – p2p sync to my parents PC – this is good for anything, bar nuclear strike :(
3) Google Drive for my working docs (5GB)
4) Dropbox/SkyDrive for my music/photos files (16+25GB)
Other services, like UbuntuOne, SugarSync, MegaCloud, Bitcasa – I do not see much use for, with current pricing. I will however, try them to see if I missed anything.
I use both phones in parallel during the trip to Crimea, Ukraine, and even took some comparative shots.
Only XT720 photos
Notice in the left side of the photos below, this is my finger. Happens to often with XT720, due to placement of the camera on the very edge of the phone, too close to the point, where you naturally keep your fingers.
Using flash in the poorly lit museum, during daytime. No nighttime pics yet.
Motorola XT720 on the left, Samsung Omnia i8910 on the right
My overall verdict stays the same, photo quality of XT720 is quite average, hopefully this will change in the next firmwares.
Just received by DHL. Bought at Expansys.lv (Latvian version of expansys.co.uk). Phone was delivered from warehouse in Marseille, France.
Some notes – very nice build quality, rubberised metal on the backside, nice display, TFT with mirror underneath, so it looks ok in the direct sunlight. Strange, you cannot work with this phone without SIM, only emergency calls allowed. Another negative, about body construction – the blue border around lense (2nd picture here) is very razor sharp and collects particles of my pocket cloth. Finally, a nice touch, 8GB SD card is included.
I did not check processor speed, but it is slower than Samsung Galaxy S that I used previously, so maybe it really is 550MHz, but Motorola promised to up that to 720MHz in the new firmware and to upgrade OS to Android 2.2.
re: last photo here – in the top right corner you can see indicator of filming mode (camera in this case). I expected that it is sensitive button, but, alas, I cannot make it switch modes by touching any of those indicators. You need to go to on-screen menu to change modes.
If your mobile phone is not Android or iPhone… or your gmail still does not have Google buzz folder, you still can get into buzz, albeit only mobile version. Use Firefox extension – UserAgentSwitcher. Choose iPhone3.0 profile, go to buzz.google.com.
You can also buzz from symbian (and I presume winmo, although I haven’t tested it) goole maps (v.4.0) which was updated yesterday on google servers. Works on Symbian s60v5.
Believe or not believe? I tend to believe, seeing that HTC HD2 is made to satisfy these specifications and that it was promised that HD2 will get upgrade to WM7. And just to put those specs into perspective, my Raon Everun UMPC ran Windows XP with just 6GB SSD and 600MHz CPU. Just asked Eldar if so high requirements may mean that Windows Mobile 7 is a some kind of light weight rehash of Windows XP, and he replied that it really looks so.
So will we get XP compatibility in new Windows Mobile 7 phones? Not 100% I think, but with some UI adjustments, recompiling existing XP code might be an option.
